GE FAUNC IC697VAL134 Converter Board

IC697VAL134

GE FAUNC IC697VAL134 Converter Board

The IC697VAL134 is a GE Converter Board.

  • Item NO.:

    IC697VAL134

  • Payment:

    T/T

  • Market Price:

    $1000

  • Product Origin:

    United States (US)

  • Product weight:

    1kg

  • Lead Time:

    In stock

  • Shipping Port:

    Xiamen
Inquire Now
Contact Us:

 » Description
 Manufacture  GE
 Model  IC697VAL134
 Product ID  IC697VAL134
 Catalog  GE FANUC
 Description  IC697VAL134 Converter Board
 Origin  United States (US)
 Dimension  34 mm x 145 mm x 140 mm
 Weight  1kg



IC697VAL134



IC697VAL134



The IC697VAL134 board is a converter board that has been designed and manufactured by GE Fanuc. The specific purpose of this board is to work as a signal converter device. It can scan analog input channels and convert the signal from analog to digital. The specific converter that comes embedded in the board is an ADC converter with a resolution of 12 bits. This board does not require the use of any software after it has been powered up and it starts scanning each input channel. The GE Fanuc Automation IC697VAL134 converter board has an input range that goes from +/- 50 minivolts to +/- 10 Volts DC and it comes with input overvoltage protection features. The IC697VAL134 converter board includes a front panel LED that indicates the status of the inputs. This board occupies 128 bytes of I/O VMEbus space and it comes with jumpers that provide space for a board on any 128-bytes boundary. Before installing IC697VAL134, the equipment needs to be deenergized to ensure safety during the installation process to both the equipment and the technicians.
Features:
• Thirty one single-ended or 16 differential inputs
• Autoscanning; continuously digitizes inputs and stores results in dual-ported data registers
• Input ranges from ±50mV to ±10V
• Jumper-programmable gains of x1, x10, x100
• Selectable A/D ranges of ±5V, ±10V, 0 to +10V
• Aggregate conversion rate of 40kHz
• Supports real time Built-in-Test
• Input connector compatible with discrete wire cables
• Selectable data coding; offset binary or two’s complement
• Overvoltage protected inputs
• Low pass input filters: 40Hz (IC697VAL134)
• Pull-down resistors prevent floating inputs
• Channel-to-bus isolation to 1,500V
• Accepts pluggable barrier strip cable connector with user screw interface


  •  » Datasheet Link

GE FANUC IC697VAL134 Converter Board Datasheet



  • # Quality
    100% brand new and original
    All the goods will be tested before shipment.
  • # Warranty
    Topteng offers a 12-month warranty from the date of delivery
    In the event of non-conforming product (if damaged or incorrect product is received),
    Any nonconformity must be reported within 7 days of receipt of goods.
  • # Delivery Time
    For the in stock items, we will send the order out within 5-7 days after receive the payment.
    We can shipping all over the world via DHL,UPS,Fedex and EMS
