The BC810 7TBA010800R0083 is a 1-1/4 IN NMD90 Zinc Connector manufactured by ABB.
Item NO.:
BC810 7TBA010800R0083Payment:
T/TMarket Price:
$1300Product Origin:
SwedenProduct weight:
1.5kgLead Time:
In stockShipping Port:
Xiamen
|
» Description |
| Manufacture | ABB |
| Model | BC810 |
| Product ID | 7TBA010800R0083 |
| Catalog | Advant 800xA |
| Description | BC810 7TBA010800R0083 1-1/4 IN NMD90 Zinc Connector |
| Country of Origin | Sweden |
| Dimension | 127.5mm*59mm*185mm |
| Weight | 1.5kg |
The BC810 unit consists of two basic parts: baseplate (TP857) and power supply/logic board. The baseplate is where the connectors to CEX-Bus and the external power reside. It is grounded to the DIN-rail through metal parts of the housing. The board also carries the external power voting diode and fuse. The power supply and logic board contains the +3.3 V converter, logic, drivers for CEX-Bus interconnection and the connector for interconnection cable.
BC810 can be used with PM861A, PM862, PM864A, PM865, PM866, PM866A and PM867.
Features and benefits:
• Supports redundant communication interface units.
• Supports on-line replacement of the CPU.
• External power supply.
• Supports hot swap.
|
ABB BC810 7TBA010800R0083 1-1/4 IN NMD90 Zinc Connector Datasheet
